HikMicro Falcon 2.0 FQ50 Thermal Imaging Camera
This HikMicro Falcon 2.0 FQ50 thermal imaging camera has a cylindrical shape, which makes it very comfortable to hold. The housing is made from a strong and lightweight magnesium alloy. Compared to its predecessor, it has a significantly greater sensitivity, which means more details are shown. The display is bigger and the HSIS (HikMicro Shutterless Image System) lets the thermal imaging camera adjust itself quickly and silently to changes in infrared radiation without noisy clicks or delays.
Many image modes (colours) are available, which means there’s a suitable image for every circumstance and every preference. Through Wi-Fi, images can be transferred or streamed to a smartphone, but – of course- the thermal imaging camera also has its own internal data storage. The battery life for continuous use (depending on circumstances) lies around 6,5 hours.
Features of the HikMicro Falcon 2.0 FQ50 thermal imaging camera:
Thermal module
• Sensor: VOx Uncooled Focal Plane Arrays
• Sensor resolution: 640x512 pixels
• Pixel size: 12 µm
• NETD: < 15 mK
• Detection range: 2600 metres
• Objective: 35 mm
• Magnification: 2,7 – 21,6x (8x zoom)
• Field of view: 8,8 x 7° (15,4 x 12,2 metres at 100 metres)
• Display: 0,49” OLED
• Display resolution: 1920 x 1080 pixels
• 6 colour palettes: black hot, white hot, red hot, red monochrome, green monochrome, fusion
Photo/video
• Video recording possible
• Photo storage possible
• Sound recording possible
• Internal data storage
Power
• 2x rechargeable and replaceable 21700 battery
• USB-C connection for external 5V DC 2A power source (also for charging)
• +/- 6,5 hours continuous use at 25°C with WiFi and LRF on
Other features
• Dioptric range: -5 tot +3 D
• Wi-Fi: 2,4/5 GHz
• IP67 waterproof (dust proof, dip proof)
• Weight: 570 grammes
Specifications
| Brand | HikMicro |
| Series | HikMicro Falcon |
| Product code | FQ50 2.0 |
| Type | Handheld |
| Sensor resolution (pixels) | 640x512 |
| Pixel pitch (µm) | 12 |
| Thermal sensitivity (NEDT mK) | ≤15 |
| Optical magnification | 2.7x |
| Digital magnifcation | 2x, 4x, 8x |
| Objective diameter (mm) | 50 |
| Reticle | No |
| Focus | Adjustable objective |
| Display type | OLED |
| Display resolution | 1920x1080 |
| Frame rate (Hz) | 50 |
| Stream function | Yes |
| Battery type | 21700 |
| Battery life | 6.5 hours |
| IP-code | IP67 |
| Size (mm) | 205×69.6×82.9 (l×w×h) |
| Weight (gram) | 596.5 |
| Mounts included | No |
| Extras | 2 batteries, Battery charger, Carrying bag, Cleaning cloth, Lanyard, Neck strap, USB cable |
